Specification 规格
| MPCV | 02 | A | 1 | C |
|---|---|---|---|---|
| Product Series | Port Size | Control Port 控制油口 | Pressure Adjusting Range (bar) 压力调整范围 | Design No. |
Modular Pilot Operated Check Valve Series 叠加式液压锁 | 02: 1/4" | A: A port B: B port W: A & B port | 1: 0.5 2: 5 12: 2.5 | |
| 03: 3/8" |
Model No.型号
MPC-02-B-1-C, MPC-02-W-1-C, MPC-03-A-1-C, MPC-03-B-1-C, MPC-03-W-1-C
Conversion Table:转换表
| Model | Size | ISO | CETOP | NFPA | DIN | |
|---|---|---|---|---|---|---|
| 02 | 1/4" | 6mm | ISO 03 | CETOP 3 | D03 | NG 6 |
| 03 | 3/8" | 9mm | ISO 05 | CETOP 5 | D05 | NG 10 |
Model Code 型号代号
Measurement 尺寸
